MODELING - BIM

LLSD is a well established steel detailing firm that has been around for about 35 years now. There's not allot of easy clean buildings out there that lend themselves to using modeling software, but when we get one, it's nice to be sure that everything fits and that there are no problems that weren't caught because a drafter missed something. It is also very true that "Shit in, shit out", so if someone puts the wrong size of plate, bolts, beams or the model will not know that it is wrong, so you need experienced detailing to catch those kind of problems!
DOPPLER VOR
BROADWAY MEDICAL ISO
BUSINESS CENTER ISO
BUSINESS CENTER ISO (NO WALLS)
